Y-MAP-Net

We present Y-MAP-Net, a Y-shaped neural network architecture designed for real-time multi-task learning on RGB images. Y-MAP-Net simultaneously predicts depth, surface normals, human pose, semantic segmentation, and generates multi-label captions in a single forward pass. To achieve this, we adopt a multi-teacher, single-student training paradigm, where task-specific foundation models supervise the learning of the network, allowing it to distill their capabilities into a unified real-time inference architecture. Y-MAP-Net exhibits strong generalization, architectural simplicity, and computational efficiency, making it well-suited for resource-constrained robotic platforms. By providing rich 3D, semantic, and contextual scene understanding from low-cost RGB cameras, Y-MAP-Net supports key robotic capabilities such as object manipulation and human–robot interaction.

One click deployment in Google Collab :

---

Features

• Real-time inference from webcam, video files, image folders or screen capture
• Multi-task outputs: 2D pose (17 COCO joints), depth, surface normals, segmentation, and text token embeddings
• Multiple backends: TensorFlow, TFLite, JAX and ONNX
• Interactive web UI via Gradio

---

Youtube Supplementary Video of Y-MAP-Net

Quick Start

1. Setup

# Automated setup (creates a virtual environment and installs dependencies)
scripts/setup.sh
source venv/bin/activate

Or using Docker:

docker/build_and_deploy.sh
docker run ymapnet-container
docker attach ymapnet-container
cd workspace
scripts/setup.sh
source venv/bin/activate

2. Download a Pre-trained Model

scripts/downloadPretrained.sh

3. Run

./runYMAPNet.sh

This starts real-time pose estimation from your default webcam.

To perform vehicle counting (supplementary example)

wget http://ammar.gr/datasets/car.mp4
./runYMAPNet.sh --from car.mp4 --fast --monitor Vehicle 100 128 right --monitor Vehicle 190 128 left

The "left" and "right" windows will contain the detection results graph

---

Running Inference

Input Sources

# Webcam (default)
./runYMAPNet.sh

# Video file
./runYMAPNet.sh --from /path/to/video.mp4

# Image directory / sequence
./runYMAPNet.sh --from /path/to/images/

# Screen capture
./runYMAPNet.sh --from screen

# Specific video device
./runYMAPNet.sh --from /dev/video0

Common Options

Flag	Description
--size W H	Set input resolution (e.g. --size 640 480)
--cpu	Force CPU-only inference (slower)
--fast	Disable depth refinement, person ID, and skeleton resolution for speed
--save	Save output frames to disk
--headless	Run without any display window
--illustrate	Enable enhanced visualization overlay
--collab	Headless mode with save + illustrate (useful for Colab/remote)
--profiling	Enable performance profiling

Web Interface

python3 gradioServer.py
# Open http://localhost:7860 in your browser

---

Prerequisites

• Python 3.x
• TensorFlow 2.16.1+ (with CUDA 12.3+ and cuDNN 8.9.6+ for GPU support)
• Keras 3+
• NumPy, OpenCV
• See requirements.txt for the full list

Install all dependencies:

pip install -r requirements.txt
# or run the setup script:
python3 scripts/setup.sh

Pre-trained lite model downloads (development snapshot)

Format	Model	Size	Download	Engine
Keras (ICRA26)	Full	2.1GB	GDrive Link2	--engine tf
Keras (dev)	Full	1.8GB	Link	--engine tf
TFLite FP32	Lite	~268 MB	Link	--engine tflite
TFLite FP16	Lite	~210 MB	Link	--engine tflite
ONNX FP32	Lite	~268 MB	Link	--engine onnx
ONNX FP16	Lite	~209 MB	Link	--engine onnx
JAX (npz)	Lite	~268 MB	Link	--engine jax

To use a different engine you need to invoke it in the following way :

./runYMAPNet.sh --engine onnx

COCO17 Evaluation

To evaluate the model against COCO17 follow the following commands from the root directory of the project :

wget http://ammar.gr/ymapnet/archive/ymapnet_coco_validation_dataset.zip
unzip ymapnet_coco_validation_dataset.zip
python3 evaluateYMAPNet.py

---

Citation

If you find our work useful or use it in your projects please cite :

@inproceedings{qammaz2026ymapnet,
  author = {Qammaz, Ammar and Vasilikopoulos, Nikos and Oikonomidis, Iason and Argyros, Antonis A},
  title = {Y-MAP-Net: Learning from Foundation Models for Real-Time, Multi-Task Scene Perception},
  booktitle = {IEEE International Conference on Robotics and Automation (ICRA 2026), (to appear)},
  year = {2026},
  month = {June},
  projects =  {MAGICIAN}
}

License

FORTH License — see LICENSE for details.
