Wi-Fi QR Code Generator

Create professional Wi-Fi QR codes in seconds. This app runs entirely in the browser, supports WPA/WPA2, WEP, and open networks, and lets you export PNG or SVG with adjustable size and error correction.

Live: https://sagarbiswas-multihat.github.io/WiFi-QR-Generator/

Why this project

If you share Wi-Fi often, typing passwords is slow and error-prone. This tool generates the standardized QR payload so phones can connect instantly. No accounts, no backend, and no data leaves your device.

Features

• WPA/WPA2, WEP, and open network support.
• Hidden SSID option.
• Adjustable QR size and error correction.
• Export PNG or SVG.
• Copy the raw Wi-Fi payload for advanced use.
• No storage, no tracking, no backend.
• Clean, responsive UI that works on mobile and desktop.

Quick start

1. Open index.html in a modern browser.
2. Enter your SSID and password.
3. Choose security type, size, and format.
4. Click "Generate QR code".
5. Scan or download the QR code.

How it works

The generator builds a standard Wi-Fi QR payload like this:

WIFI:T:WPA;S:MyNetwork;P:MyPassword;H:true;;

• T is the auth type (WPA, WEP, or nopass).
• S is the SSID.
• P is the password (omitted for open networks).
• H:true is used when the SSID is hidden.

Reserved characters in SSID or password (\, ;, ,, :, ") are escaped before encoding.

Settings guide

• Security type
  • WPA/WPA2: password length 8-63 characters.
  • WEP: 5 or 13 ASCII characters, or 10 or 26 hex characters.
  • No password: no password required.
• Hidden network: include H:true in the payload.
• QR size: visual size in pixels.
• Error correction: more correction increases reliability but makes the QR denser.
• Format: PNG for raster images, SVG for crisp scaling in print.

Project structure

.
├── index.html
├── style.css
├── script.js
├── lib
│   └── wifi-qr.js
├── tests
│   └── wifi-string.test.js
├── .github
│   └── workflows
│       └── python-ci.yml
└── LICENSE

Development

No build step is required. Open index.html in your browser.

If you want to run tests locally:

npm test

CI

GitHub Actions runs the tests on every push and pull request to main using the workflow in .github/workflows/python-ci.yml.

Offline use

The QR library is loaded from a CDN by default. To run fully offline:

1. Download qrcode.min.js from https://github.com/soldair/node-qrcode
2. Save it next to index.html.
3. Replace the CDN script tag with a local reference.

Privacy and security

• All data stays in your browser.
• Nothing is stored or transmitted.
• Close the tab to clear everything.

Troubleshooting

• "QR code library failed to load": Check your connection or switch to the offline setup above.
• WPA password rejected: Must be 8-63 characters.
• WEP password rejected: Use 5/13 ASCII or 10/26 hex characters.

Compatibility

Works in current versions of Chrome, Edge, Firefox, and Safari.

Contributing

Issues and pull requests are welcome. Please include clear reproduction steps and screenshots for UI bugs.

License

MIT. See LICENSE.
