Magical Mixing Console

Free and open source app for Behringer X Air and M Air digital mixers.

Download from the releases page.

If looking for a Node.js library for communicating with X Air devices only, check out magical-mixers.

This software is provided as-is, without warranty or support. It communicates with your mixer over the local network; no usage data is collected.

Trademarks: Behringer, Midas, X Air, and M Air are trademarks of their respective owners. This project is not affiliated with or endorsed by Music Tribe or Behringer.

Feel free to fork it, build crazy versions, add support to other brands/models, or whatever. If distributing, use your own name/logo for avoiding clashes.

Built with ❤️ by Matías Barrios in Piriápolis, Uruguay 🇺🇾. Aguante la música ✨

Quick start

Install dependencies

git clone https://github.com/matiasbarrios/magical-mixing-console.git
cd magical-mixing-console
npm install

Install a couple of Capacitor plugins:

git clone https://github.com/matiasbarrios/capacitor-udp-socket.git plugins/capacitor-udp-socket
cd plugins/capacitor-udp-socket
npm install
npm run build
cd ../..

git clone https://github.com/matiasbarrios/capacitor-navigation-bar.git plugins/capacitor-navigation-bar
cd plugins/capacitor-navigation-bar
npm install
npm run build
cd ../..

Run a virtual device

If you don't have a real one:

cd src/virtual-devices
npm run x18
cd ../..

Desktop version

In dev mode:

npm run electron-dev

The app should open showing the following screen:

Mobile version

Before building for mobile:

1. Set appId and appName in capacitor.config.json if you fork and publish your own build (defaults use com.opensource.magicalmixing.console / Open-Sourced Magical Mixing Console so they do not collide with the commercial app).
2. Run npm run cap-make.
3. Add native projects: npx cap add android and/or npx cap add ios.
4. Configure signing in Android Studio / Xcode for your own store accounts.

In dev mode:

npm run cap-dev
npm run cap-android
npm run cap-ios

Documentation

Full index: docs/README.md

Document	Purpose
docs/development/DEVELOPMENT.md	Clone, plugins, npm scripts, iOS/Android dev notes
docs/development/DEBUGGING_NETWORK.md	Wireshark filters for OSC/UDP
docs/reference/ARCHITECTURE.md	Layers and where to change code
docs/reference/CONCEPTS.md	Mixer domain model
docs/reference/CONNECTIVITY.md	Device search, sockets, platform UDP
docs/gui/GUI.md	GUI conventions
docs/gui/LIST_PATTERN.md	List UI patterns
docs/TESTING.md	Automated tests

Contributing

Questions and architecture help → Discussions. Bugs and scoped work → Issues.

See CONTRIBUTING.md for setup, layer guide, tests, and PR notes.

License

Apache License 2.0 — see LICENSE.
