KML Generator

Excel & VBA Based KML Generator for Geolocation Visualization on Google Earth and GIS Tools

[Open/Close] Table of Contents

• KML Generator
  • Description
  • Technologies
  • General Settings
  • Usage
  • Repository Structure
  • Architecture
  • Output Example
  • Versions

📄 Description

The KML Generator automates the creation of .kml files based on coordinate tables maintained in an Excel sheet.

The project includes:

• A ready-to-use Excel template (dados_kml.xlsm)
• All VBA modules already imported
• A standardized table format ready for modification
• Built-in validation for colors, coordinate formats, and structure integrity

💡 Technologies

• Excel (.xlsm)
• VBA
• KML format
• Google Earth-compatible

⚙️ General Settings

Excel Model Structure

The file dados_kml.xlsm contains:

• All VBA modules pre-imported (funcoes.bas, gerar_kml.bas)
• A fully prepared structure for edition
• Columns preconfigured for KML generation
• Validation of allowed colors for IconCor

Column Rules and Constraints

You may:

• Add or remove columns before the Drive column (yellow KMZ stage).
• Add metadata fields.

You may not:

• Add columns after IconCor
• Change the order of required columns

Required final structure:

Link Description	Latitude	Longitude	IconText	Drive	IconCor

Format Requirements

• Latitude/Longitude format (must include degree symbol °):

  37.235000°
  -115.811111°


• Drive must be a URL link to a folder
• IconCor only accepts implemented script colors

IconCor Allowed Colors

vermelho
amarelo
verde
branco

🚀 Usage

Input Example

Link Description	Latitude	Longitude	IconText	Drive	IconCor
Folder	37.235000°	-115.811111°	Galpão	https://drive/folder	amarelo

Generate KML

Developer → Macros → gerar_kml

📁 Repository Structure

/kml-generator
├── dados_kml.xlsm
├── funcoes.bas
├── gerar_kml.bas
├── LICENSE
└── README.md

⚙️ Architecture

• Input Layer (Excel)
• Processing Layer (VBA)
• Output Layer (KML)

🔎 Output Example

<Placemark>
  <name>Galpão</name>
  <Point>
    <coordinates>37.235000°, -115.811111°</coordinates>
  </Point>
</Placemark>

🚧 Versions

Version 1.1 – 2025/02/11

• Documentation updates
• Added IconCor constraints
• Added Drive rules
• Updated Excel model instructions
